镍基合金锻件,N08825,化学成分,力学性能,B564
镍基合金锻件N08825的化学成分和力学性能-B564
材料:不锈钢 碳钢 合金钢
交期:标准法兰常年现货
描述:联系站长免费领取法兰标准及重量表
规格: DN20-DN3000
在线咨询
  • 产品详情

    ASTM B564-2015 Nickel Alloy Forgings



    Alloy Type: Ni-Fe-Cr-Mo-Cu



    UNS Designation: N08825



    Features

    Alloy 825 has excellent resistance to chloride-ion-induced stress corrosion cracking, reducing environments containing phosphoric and sulfuric acids, oxidizing environments containing nitric acid and nitrates, and pitting, crevice corrosion and intergranular corrosion. It has good mechanical properties at cryogenic temperatures to moderately high temperatures up to 538 ℃.



    Applications

    Chemical process industry, acid production, picking equipment, pollution control equipment.



    Ordering Information

    It is the responsibility of the purchaser to specify all requirements that are necessary for material ordered under this specification. Examples of such requirements include, but are not limited to, the following:

    1 Alloy type.

    2 Condition.

    3 Quantity (mass or number of pieces).

    4 Forging, sketch or drawing.

    5 Certification-State if certification or a report of test results is required.

    6 Samples for Product (Check) Analysis—Whether samples for product (check) analysis should be furnished.

    7 Purchaser Inspection—If the purchaser wishes to witness tests or inspection of material at the place of manufacture, the purchase order must so state indicating which tests or inspections are to be witnessed.



    Chemical Requirements: Composition, %

    Ni: 38.0-46.0

    Cu: 1.50-3.00

    Fe: ≥22.0

    Mn: ≤1.00

    C: ≤ 0.05

    Si: ≤0.50

    S: ≤0.03

    Cr: 19.5-23.5

    Al: ≤0.2

    Ti: 0.6-1.2

    Mo: 2.5-3.5



    Mechanical Property Requirements

    Condition: annealed

    Tensile Strength: ≥586MPa

    Yield Strength: ≥241MPa

    Elongation in 2 in. or 50 mm (or 4D), %: ≥30
